Jonard tools UST-540 Universal Cable Stripping Tool with Cable Stop for COAX, Network, and Telephone Cables
Description
The Jonard Tools UST-540 cable stripping tool is designed to strip COAX, Network Cables, and Telephone Cables for quick and easy termination. This universal stripping tool features the following:
Features:
- Included blade cartridge (UST-240) provides a 2-level strip on RG59 and RG6 COAX Cables for F, BNC, and RCA connector termination
- High carbon steel blades last over 5,000 strips on each side
- Cable stop on one side of the cartridge ensures precise stripping without need to make adjustments
- Cartridge is reversible for ambidextrous use
- Adjustable stripping hole is used to strip CAT3/4/5E/6/6A PVC and Plenum network cables
- Cutter is included to cut all types of cables
- Separate stripping slot included for stripping Flat Cable & 4P/6P style cable
- Hook and Loop strip on bottom of the tool folds back the braided shield on the cable with ease
- Large finger loop provides smooth rotation during use
- Stripping action removes 1/4″ of jacket and 5/16″ of shield and dielectric, which exposes the center conductor
Cable Type
Cable Type: RG59 and RG6
Specifications
Cable Type | COAX, Network, Flat Telephone Cable |
---|---|
Cable Size | RG-59/6 COAX, CAT3/4/5E/6/6A Network, Up to 1 cm wide Flat Cable |
Dimensions | 4.92 in X 2.79 in X 0.95 in (12.48 cm X 7.07 cm X 2.4 cm) |
Weight | 0.15 lb (66.284 g) |
UPC # | 811490017696 |
