Description

Features:

• 3 5/6 Digital Smart Measurement
• 3 5/6 digits 5999 counts, 0.5% best accuracy
• Auto Selection of ACA, ACV, DCV, Resistance, and Frequency
• Auto Range for convenient and accurate measurement
• Simultaneous Measurement
• Dual display enables you to display frequency while measuring AC Voltage, AC; or while measuring AC Current simultaneously measure with AC/DC Voltage and Resistance.
• Noncontact ACV detector for AC 90-1000V AC peak current measurementDual Display with backlight allows operation in dark areas.  Display the results of simultaneous measurement
• NCV Detection
• Diode Test
• Continuity Test
• Transistor Test
• Data Hold
• Low Battery Indication
• Backlight

Specifications:

• ACA: 6A /60A/400A±(2.5%+8d), 600A±(3.0%+10d), PEMAX: 900A ±(10%+10d)
• ACV: 6V /60V/600V ±(0.8%+5d)
• DCA: 6V /60V/600V ±(0.5%+3d)
• Accuracy: 0.5% best accuracy
• Resistance: 6K/60K/600K/6M/10MΩ ±(0.8%+3d)
• Frequency: 10~1kHz±(1.0%+5d)
• NCV: 90~1000V 50/60Hz
• Extra functions: Data hold, LCD backlight, Low Battery, Auto power off
• Battery: 1.5V AAAx2 (not included)
• Size: 190 x 68 x 38 mm
• Individual packing: Color box
• Accessories: Test lead, Carry bag
